For miter cuts up to 45° left in fully automatic Operation and up to 60° left in semi-automatic operation Material height sensor (automatic cut start detection) Automatic feed unit via ball screw with incremental feed automatic length compensation Button on the saw band for automatic adjustment of the saw stroke Fully automatic control of the saw frame and clamping device Hydraulic unit with automatic pressure shut-off when idling Mechanical chip clearing brush feed vice opening on both sides Remaining piece length 100 mm Modern CNC control freely programmable for multiple sawing jobs with various Cutting lengths and quantities. Automatic feed unit 500 mm via ball screw incremental feed with automatic length compensation. Adjustable for section lengths of 25 – 9,999mm. Fully hydraulic control of saw frames and clamping devices Preselection of 3 different material feed speeds Visualization of the entire workflow with simple data entry

• capacity 90 degrees: round 510 mm
• capacity 90 degrees: square 480 mm
• saw band length 5320 x 34 x 1,1 mm
• band speed 15 - 100 m/min
• table height 820 mm
• total power requirement 3,0 kW
• weight of the machine ca. 2,3 t
• dimensions of the machine ca. 2,65 x 2,8 x 2,2 m

• No additional information specified

• no accessories specified
